LND-6012R
2MP IR Dome Camera

Key Features
• Maximum 2MP resolution
• Color: 0.03Lux(F2.0, 1/30sec) BW : 0Lux (IR LED on)
• 2.8mm fixed focal
• Maximum 30fps@2MP (H.264)
• H.264, MJPEG codec supported, Multiple streaming
• Day & Night (ICR), WDR (120dB)
• Tampering, Motion detection
• Micro SD/SDHC/memory slot (32GB), PoE
• Hallway view(90˚/270˚), WiseStreamII support
• IR viewable length 20m(65.62ft)

LND-6072R
2M IR Dome Camera

Key Features
• Maximum 2MP resolution
• Color: 0.03Lux(F1.6, 1/30sec) BW : 0Lux (IR LED on)
• 3.2~10mm(3.1x) manual varifocal
• Maximum 30fps@2MP (H.264)
• H.264, MJPEG codec supported, Multiple streaming
• Day & Night (ICR), WDR (120dB)
• Tampering, Motion detection
• Micro SD/SDHC/memory slot (32GB), PoE
• Hallway view(90˚/270˚), WiseStreamⅡ support
• IR viewable length 20m(65.62ft)

LRN 1610 S
• Up to 16CH 5MP
• H.265, H.264, MJPEG codec
• 100Mbps network camera recording
• Plug & play by 16 PoE ports
• Up to 2 SATA (12TB)
• HDMI local monitor
• P2P service (QR code connect)

• Max. 5MP resolution
• 2.7~12mm(4.4x) motorized varifocal lens
• 0.15Lux (Color), 0Lux (B/W, IR LED on)
• Max. 30fps@5MP (H.265 / H.264)
• H.265, H.264, MJPEG codec support, Multiple streaming
• Day & Night, WDR (120dB)
• Tampering, Motion detection, Defocus detection
• MicroSD / SDHC / SDXC memory slot (Max. 128GB)
• Hallway view, WiseStream II support
• IR Viewable length 30m
• IP66, IK10, PoE, DC 12V

*Available in Hanwha Vision Middle East and Africa Only – QNO-8081R/KME

QRN-430S
4CH NVR

Key Features
• Up to 4CH 8MP resolution
• H.265, H.264, MJPEG codec
• 40Mbps network camera recording
• Plug & play by 4 PoE port
• Max. 1 HDD (Up to 6TB)
• HDMI output
• P2P service (QR code)

QRN-810S
8CH 8M H.265 NVR with PoE Switch

Key Features
• Up to 8ch 8megapixel supported
• H.265, H.264, MJPEG codec supported
• 80Mbps network camera recording
• Plug & play by 8 PoE ports
• Max. 1HDD supported
• HDMI local monitor
• P2P service (QR code connect) support

Up to 64 Channels, Maximum 12 megapixel camera supported
Maximum 300Mbps network camera recording
Support 4K video out on HDMI monitor
Support dual monitor video out
Support H.265, H.264, MJPEG compression
WiseStream support
Maximum 8 internal HDDs (64TB), e-SATA storage support
ARB & failover (N+1) support
QR code for easy mobile app access

XRN-2011 A
• Up to 32CH, Max. 12MP Camera supported
• 256Mbps network camera recording
• Support 4K video out on HDMI monitor
• Support Dual monitor video out
• Support H.265, H.264, MJPEG compression
• WiseStream support

XRN-3210RB2
32CH NVR

Key Features
• Up to 32CH, 32MP Resolution
• Max. 400Mbps network camera recording
• HDMI out
• User friendly UI / UX
• AI search support when working with Wisenet AI camera
• Dynamic Event support
– New event function of cameras is available without software update
• Bookmark management (Up to 100 set)
• H.265, H.264, MJPEG compression support
• SATA 8ea (Up to 80TB, Non-RAID mode)
• RAID 5/6 support

XRN-6410RB2
64CH NVR

Key Features
• Up to 64CH, 32MP Resolution
• Max. 400Mbps network camera recording
• HDMI out
• User friendly UI / UX
• AI search support when working with Wisenet AI camera
• Dynamic Event support
– New event function of cameras is available without software update
• Bookmark management (Up to 100 set)
• H.265, H.264, MJPEG compression support
• SATA 8ea (Up to 80TB, Non-RAID mode)
• RAID 5/6 support

LNO-6012R
2MP IR Bullet Camera

Key Features
• Maximum 2MP resolution
• Color: 0.03Lux(F2.0, 1/30sec) BW : 0Lux (IR LED on)
• 2.8mm fixed focal
• Maximum 30fps@2MP all resolutions (H.264)
• H.264, MJPEG codec supported, Multiple streaming
• Day & Night (ICR), WDR (120dB)
• Tampering, Motion detection
• Micro SD/SDHC memory slot (32GB), PoE
• Hallway view (90°/270°), WiseStreamII support
• IR viewable length 30m(98.43ft)
• IP66 support

LNO-6072R
2MP IR Bullet Camera

Key Features
• Maximum 2MP resolution
• Color: 0.03Lux(F1.6, 1/30sec) BW : 0Lux (IR LED on)
• 3.2~10mm(3.1x) manual varifocal
• Maximum 30fps@2MP all resolutions (H.264)
• H.264, MJPEG codec supported, Multiple streaming
• Day & Night (ICR), WDR (120dB)
• Tampering, Motion detection
• Micro SD/SDHC memory slot (32GB), PoE
• Hallway view (90°/270°), WiseStreamII support
• IR viewable length 30m(98.43ft)
• IP66 support

QNV-6072R
2M H.265 IR Dome Camera

Key Features
• Max. 2megapixel (1920 x 1080) resolution
• 0.03lux (Color), 0Lux (B/W, IR LED on)
• 3.2 ~ 10mm (3.1x) varifocal lens
• Max. 30fps@2M all resolutions (H.265/H.264)
• H.265, H.264, MJPEG codec supported, Multiple streaming
• Motion detection, Tampering, Defocus detection
• Hallway view (90°/270°), LDC support
• Micro SD/SDHC/SDXC memory slot (Max. 128GB)
• IR viewable length 30m
• IP66, IK10, PoE/12VDC

QNV-7082R
4MP IR Vandal Dome Camera

Key Features
• Max. 4MP resolution
• Color : 0.1Lux (F1.6, 1/30sec), B/W : 0Lux (IR LED On)
• 3.2 ~ 10mm (3.1x) motorized varifocal
• IR viewable length: 30m (98.42ft)
• Day&Night (ICR), WDR (120dB)
• H.265, H.264, MJPEG, Multiple streaming supported
• Motion detection, Tampering, Defocus detection
• Hallway view (90°/270°), LDC support
• Micro SD/SDHC/SDXC memory 1 slot (Max. 128GB)
• IP66, IK10

• QHD (2560 x 1440, 30fps) resolution
• 0.16 Lux@F1.6 (Color), 0 Lux (B/W : IR LED on)
• 3.2 ~ 10mm (3.1x) varifocal lens
• Day & Night (ICR), DWDR, Motion detection
• Transmission distance Max. 500m
• Easy installation (Plug & play), Dual power
